Delivery Date:
10/17/2017
Department Name:
Coolbaugh TWP Volunteer Fire Department
Department City / State:
Coolbaugh, PA
Truck Type:
WHEEL BASE: 232”
TRAVEL HEIGHT: 120 9/16”
TRAVEL LENGTH: 35’- 2 ¼”
CHASSIS: Sutphen 73” extended cab with half 10” raised roof
- Four-Door, Eight-Person Cab
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins ISL 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- 1250-Gallon Water Tank
BODY: Sutphen
- Stainless Steel
- Hinged Compartment Doors
- 6 cu. ft. total compartment space
- Alco-Lite PEL-24
OPTIONAL EQUIPMENT:
- 5000 Watt Honda Generator
- Traffic Advisor, Whelen
- Camera System, Safety Vision SV-CLCD0-70
- Intercom, Firecom, Radio Model-Motor XPR 5550
- Federal Q2B
- 24” Bumper
- Pike Pole Storage Tubes
