WHEELBASE: 182”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 29′ – 8 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right, (1) 1 ½” Right, (1) 3” Pipe to Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 3” Deck Gun
- Crosslays: (4) 2” Valve-Piping 1 ½” Swivel
- 750-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors
- 170 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
- Body: PS-02 RES 30/47 Ladder Chute
ADDITIONAL EQUIPMENT:
- 12” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Single Camera
- FRC Spectra LED Brow Light
- Whelen Freedom IV 72” LED Light Bar
- Opticom Mounted in Lightbar
- FRC Spectra Tele Lights
- FRC Spectra LED Scene Lights
