Delivery Date:
10/12/2022
Department Name:
City of Douglas Fire Department
Department City / State:
Douglas, GA
Truck Type:
Sutphen Corporation – HS #7113
Dealer – Williams Fire Apparatus
WHEELBASE: 185”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 31′ – 4”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 19,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Left of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (1) 2 ½”
- Speedlay: (2) 2” w/ Swivels & Poly Lift-Out Trays
- 1,000 -Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- AMDOR Roll-Up Compartment Doors
- 246 cu. ft. Total Compartment Space
- Alco Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladders through Tank
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras
- Hannay Electric Cord Reel, 150’ (1)
- Generator: 6KW Smart Power
- FRC Spectra Brow Light
- Whelen Freedom LED Lightbar
- FRC 900 LED Scene Lights
- FRC Spectra Telescopic Lights
- FireTech LED Work Lights
- Whelen LED Traffic Advisor
