Delivery Date:
09/25/2020
Department Name:
Chippewa Township Fire Department
Department City / State:
Doylestown, Ohio
Truck Type:
Sutphen Corporation – HS #6609
Dealer – Herb Fire Equipment
WHEELBASE: 215”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 34’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (2) 2” w/ 1 ½” Swivel
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-Up Compartment Doors
- 251 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Body: G9-Alum 43/53 Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC Inview Trueview Single Camera
- Whelen PFH2 12V Brow Light
- Whelen Freedom (10) LED Lightbar
- Whelen PFH2 12V Telescopic Lights
- Whelen M9 12V Scene Lights
- Whelen L31 Beacons
