Custom Pumper – Ceffo Volunteer Fire Department, NC

Sutphen Corporation – HS #6573

Dealer – Stevens Fire Equipment, Inc.

WHEELBASE: 185”

TRAVEL HEIGHT: 9’ – 9”

TRAVEL LENGTH: 31’ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab

• Four-Door, Four-Person Cab
• 10” Double Frame Rails (50K PSI)
• Front Axle and Suspension 20,000 lbs
• Rear Axle and Suspension 27,000 lbs
• Engine: Cummins L 9, 450 HP
• Alternator: Leece Neville, 270 AMP
• Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

• XS QMAX-1500 GPM, Single Stage Pump
• Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
• Speedlay: (2) 2” w/ Swivel & Poly Lift-out Trays
• Crosslay: (1) 2 ½”
• 1,000-Gallon Water Tank

BODY:                  Sutphen

• AMDOR Roll-Up Compartment Doors
• 222 cu. ft. Base Compartment Space
• Alco-Lite Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
• Enclosed ladder chute
• Body: G2 – Alum 40/51

ADDITIONAL EQUIPMENT:

• 24” Polished Stainless Steel Bumper
• Federal Q2B Siren, Grille Mount
• 4 Bottle Compartments (2 triple, 2 single)
• Whelen PFH2 LED Brow Light
• Whelen Justice LED Lightbar
• Whelen PFH2 Telescopic Scene Lights
• Whelen 900 LED Scene Lights
• Whelen 600 LED Red Lights
• Whelen L31 LED Red Beacons
• Whelen Ion LED Red Lights
