Delivery Date:
11/30/2024
Department Name:
Carroll County Fire Department
Department City / State:
Carrollton, GA

Dealer – Williams Fire Apparatus

WHEELBASE: 185”

TRAVEL HEIGHT: 10’ – 1”

TRAVEL LENGTH: 31’ – 4”

CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ a 10” Raised Roof

  •  Four-Door, Four-Person Cab
  • 10” Double Frame Rails, Single Axle (50K PSI)
  • Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP: Hale

  •  QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Left Rear, (1) 2 ½” Front Bumper, 2 ½” Plumbing, (1) 3” Deck Gun
  • Crosslays: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Elkhart w/ Flush
  • Foam Eductor: Akron 125 GPM External

BODY: Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Nearly 250 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
  • Body: G9 – Alum 40/51 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Two Cameras (Wired)
  • LED Roto-Ray
  • Whelen Freedom LED Lightbar
  • FireTech FT-GESM Scene Lights
  • Whelen L31 Red LED Beacons
  • Hiviz 72” Brow Light
