Delivery Date:
11/01/2021
Department Name:
Calera Fire Department
Department City / State:
Calera, AL
Truck Type:
Sutphen Corporation – HS #6937
Dealer – Williams Fire Apparatus
WHEELBASE: 185”
TRAVEL HEIGHT: 10’ – 6”
TRAVEL LENGTH: 32’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System, Akron 125 GPM 3126 By-Pass with Flush to a Discharge Line
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-Up Compartment Doors
- 301 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 28’ 2-Section, 16’ Roof & 10’ Folding
- Body: PA-13 RES 43/53, HYD Ladder Rack
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera
- Ziamatic Hydraullic Ladder Rack
- Generator: Smart Power, 10KW
- Hannay Electric Cord Reel, 150’ (1)
- Whelen Freedom 8 LED Lightbar
- Whelen M9 LED Lights
- Whelen LED Traffic Advisor
- FireTech Recessed 18” Scene Light
- FRC Spectra 12V LED Brow Light
