WHEEL BASE: 185”
TRAVEL HEIGHT: 9′ – 10″
TRAVEL LENGTH: 382”
CHASSIS: Sutphen 62” Cab with 10” half raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 20,000 Lbs.
- Rear Axle and Suspension: 31,000 Lbs.
- Engine: Cummins L9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- QMAX-2000 GPM Single Stage
- Discharge: (2) 2.5 Left, 3” Right, 2.5” Right, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
- 1500 Gallon Water Tank
- 20 Gallon Foam Tank
BODY: Sutphen
- 193 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Direct Tank Fill 5” Rear
- Hose Bed Strip Lighting
- Cab Interior Floor Covering, Two Tone Black and Gray Rubberized
- Park Brake Location
