Delivery Date:
05/22/2020
Department Name:
Apalachin Fire Department
Department City / State:
Apalachin, NY
Truck Type:
Sutphen Corporation – HS #6543
Dealer – Vander Molen Fire Apparatus Sales and Service
WHEELBASE: 207”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 32’ – 8”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 15” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 270 AMP, Dual Alternators (270 AMP each)
- Transmission: Allison, EVS4000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 1,000-Gallon Water Tank
BODY: Sutphen
- AMDOR Roll-Up and Hinged Compartment Doors
- 20 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package (28’ 2-Section & 16’ Roof & 10’ Folding)
- Body: PS-07 Res 50/47 Elec Lad Rack
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel
- Federal Q2B Siren, Grille Mount
- 7 Bottle Compartments
- Brigade Camera System
- 8KW Generator
- FR Spectra Brow Light
- Whelen Rota-Beam Lightbar
- FR Spectra Scene Lights
- Whelen M6 Warning Lights
- Whelen M9 Scene Lights
