Delivery Date:
11/19/2020
Department Name:
Alabama Fire Department
Department City / State:
Tuscaloosa, AL
Truck Type:
Sutphen Corporation – HS #6710
Dealer – Williams Fire Apparatus
WHEELBASE: 196”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 31’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Seven-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 24,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 750-Gallon Water Tank
- 30-Gallon Foam Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-Up Compartment Doors
- 150 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package (900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding)
- Body: G5 – Alum 40/51 Lowered Ladder Rack, Lowered Hose Bed
ADDITIONAL EQUIPMENT:
- 18” Formed Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview Single Camera
- Whelen PFH1 LED Brow Light
- Whelen Freedom LED Lightbar
- Whelen Tele-Lights
- Whelen M9 Scene Lights
