Delivery Date:
09/15/2021
Department Name:
Freeburg Fire Protection District
Department City / State:
Freeburg. IL
Truck Type:
Sutphen Corporation – HS #6922
Dealer – Cashion Fire Equipment
WHEELBASE: 238”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 36′ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 23,000 lbs.
- Rear Axle and Suspension: 48,000 lbs.
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: SAM IDEX System
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Deck Gun
- Crosslay: (2) 2 ½”
- Speedlays: (3) 1 ½” w/ Liftout Trays
- 2,500-Gallon Water Tank
- 75-Gallon Foam Tank
- Foam System: Hale SmartFoam 5.0
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- 130 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-35 35’ 3-Section & PRL-14 14’ Roof & 10’ Folding)
- Body: TA-04 Tanker 56/53 High/Low
ADDITIONAL EQUIPMENT:
- 12” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade 360
- Intercom: Wired/Wireless David Clark
- Hannay Booster Reel w/ 150’
- Federal Signal 73” Navigator Lightbar
- Federal Signal Mini Lightbar
- Federal Signal Traffic Advisor
- FireTech 3-Piece Brow Light
- FireTech Guardian Elite Scene Lights
- Roto-Ray Warning Light
