Delivery Date:
05/24/2023
Department Name:
Coolbaugh Township Fire Company
Department City / State:
Tobyhanna, PA

Dealer – Signal 1 Fire Equipment

WHEELBASE: 234”

TRAVEL HEIGHT: 10’ – 2”

TRAVEL LENGTH: 35′ – 1 ½”

CHASSIS:             Kenworth T-880 – 2DR Commercial Cab

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 52,000 lbs.
  • Engine: Cummins ISX 15, 605 HP
  • Alternator: Commercial Chassis
  • Transmission: EVS 4500

PUMP:                  Hale

  • Side Kick DSD, 1250 GPM, PTO
  • Discharge: (3) 2 ½” Left, (1) 2 ½” Left Rear, (1) 4” Right Side
  • Crosslays: (1) 2” w/ 1 ½” Swivel, (1) 3” Deadlay
  • 4,000-Gallon Water Tank

BODY:                  Sutphen

  • Huckbolt #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 125 cu. ft. Total Compartment Space
  • Body: SWT-05D STS Wetside Tanker Tandem, Integrated Pump

ADDITIONAL EQUIPMENT:

  • Federal Q2B Siren, Front Bumper Mount
  • Camera System: FRC, Inview 360HD w/ Built-In DVR
  • 4,000-Gallon Portable Tank w/ Zico Rack and Painted Tank Cover (2)
  • Whelen Freedom IV 60” LED Light Bar
  • Whelen 600 Warning Lights
  • Opticom Mounted in Lightbar
  • FRC Spectra Scene Light
  • Whelen 900 Warning Light
