Delivery Date:
10/17/2017
Department Name:
Highland TWP VFD
Department City / State:
Defiance, OH

WHEEL BASE: 243”

TRAVEL HEIGHT: 9’-3 ¾”

TRAVEL LENGTH: 34’-9 ¼”

CHASSIS:              International 62” with Flat Roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins ISL 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, ( 1) 3” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • 20-Gallon Foam Tank
  • Akron Foam Supply System
  • 100-Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • Amdor Compartment Doors
  • 7 cu. ft. total compartment space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • 8KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’
  • Camera System, Safety Vision SV-CLCD0-70
  • Ziamatic Quic-Lift Extended Electric Ladder Rack
