Delivery Date:
08/24/2022
Department Name:
Sparrowbush Fire District
Department City / State:
Sparrowbush, NY

Sutphen Corporation – HS #7089

Dealer – Myers Fire

WHEELBASE: 269 3/8”

TRAVEL HEIGHT: 10’ – 5”

TRAVEL LENGTH: 38’ – 6”

CHASSIS:             Freightliner SD-114 2-Door

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: 300 AMP
  • Transmission: EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Hosebed, (1) 2 ½” Right Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 1 ½” & (1) 2 ½”
  • 2,500-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Hinged Compartment Doors
  • Over 167 cu ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-section & PRL-14, 14’ Roof & 10’ Folding
  • Body: TA-04 Tanker 56/53 High/Low

ADDITIONAL EQUIPMENT:

  • 24” Bumper Extension
  • Federal Q2B Siren, Front Bumper Mount
  • Generator: Harrison 10KW
  • Hannay Electric Cord Reel, 175’ (1)
  • Camera System: Brigade, 3 Camera
  • Roto-Ray LED Warning Light
  • Whelen 62” Justice Lightbar
  • FireTech Brow Light w/ Marker Lights
  • Command Light KL415A-CH-BL
