Delivery Date:
11/16/2018
Department Name:
Richmond Volunteer Fire and Rescue Company
Department City / State:
Richmond, Ohio
Truck Type:
Sutphen Corporation – HS #6235
Dealer – Heritage Fire Equipment
WHEEL BASE: 236”
TRAVEL HEIGHT: 9’-11”
TRAVEL LENGTH: 32’-8”
CHASSIS: Freightliner M2 112 Four-Door Cab
- Four-Door, Four-Person Cab
- Front Axle and Suspension 14,600 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L9, 450 HP
- Alternator: For Commercial Chassis, 320 AMP
- Transmission: Allison EVS 3000
PUMP: Hale
- QMAX-1500 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 1 ½” and (1) 2 ½” with Swivels
- 1000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-Up Compartment Doors
- 314 cu. ft. Total Compartment Space
- Alco-LitePEL-24 (24’ 2-Section & PRL-14 14’ Roof and 10’ Folding)
- Ladder Chute with Suction Hose Storage
OPTIONAL EQUIPMENT:
- Federal Q2B Siren
- Ziamatic SAC-44 Folding Wheel Chocks
- Whelen Justice 62” LED Light Bar
- Whelen Upper Warning Lights, LED, M9 Series Surface Mount
- FR Spectra LED, Brow 20K Lumens, 12V
- Scene Lights, WHelen M9 LED
