Delivery Date:
03/17/2019
Department Name:
Nashville VFC
Department City / State:
Spring Grove, PA
Truck Type:
Sutphen Corporation – HS #6318
Dealer – Lawver Fire Apparatus
WHEEL BASE: 199”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 35’ – 5 ½”
CHASSIS: Kenworth T800- 2DR
- Two-Door, Two-Person Cab
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins ISX 15, 505 HP
- Alternator: Delco, 320 AMP
PUMP: Hale
- QMAX-1500 GPM, Single Stage
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 2 ½” Left Rear
- 3,800-Gallon Water Tank
- Crosslay: (2) 2” with 1 ½” Swivel
- Newton 10” Kwik Dump
BODY: Sutphen
- HuckBolted #304 Stainless Steel
- Amdor Roll-Up Doors
- 126 cu. ft. Total Compartment Space
ADDITIONAL EQUIPMENT:
- FRC, Trueview, Camera System
- Zico Elec Porta Tank Tack with 3,500-Gallon Porta Tank
- FRC Spectra Telelight
- Whelen 60” Freedom Lightbar
- Whelen 600 LED Warning Lights
- Whelen 900 LED, Scene Lights
- Federal Q2B Recessed in Bumper
