Delivery Date:
10/12/2018
Department Name:
Lexington Fire Department
Department City / State:
Lexington, SC

Sutphen Corporation – HS #6019

Dealer – Williams Fire Apparatus

WHEEL BASE: 156”

TRAVEL HEIGHT: 9′ – 5 1/2″

TRAVEL LENGTH: 23′ – 10 1/2″

CHASSIS:             Commercial Kenworth

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension 16,000 lbs
  • Rear Axle and Suspension 30,000 lbs
  • Engine: Paccar PX-9, 350 HP
  • Alternator: Delco 320A
  • Transmission: EVS 3000

PUMP:                 Hale

  • Side Kick APS, 500 GPM
  • Discharges: (2) 2 ½” Left
  • 2,000-Gallon Water Tank

BODY:                  Sutphen

  • Aluminum
  • Hinged Compartment Doors

OPTIONAL EQUIPMENT:

  • Federal Q2B Siren
  • Whelen Freedom IV 60” LED Light Bar
  • Whelen Scene Lights, M9 LED
  • Whelen Warning Lights
