Delivery Date:
07/19/2020
Department Name:
Shawnee Fire Company
Department City / State:
Stroudsburg, PA

Sutphen Corporation – HS #6584

Dealer – Signal 1 Fire Equipment

WHEELBASE: 200”

TRAVEL HEIGHT: 10’ – 2”

TRAVEL LENGTH: 29’ – 4”

CHASSIS:             Kenworth T880 – 2DR (Tandem)

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 46,000 lbs
  • Engine: Cummins ISX 15, 505 HP
  • Alternator: For Commercial Chassis
  • Transmission: EVS 4500

PUMP:                 Hale

  • Side Kick DSD-1000 GPM
  • Discharges: (2) 2 ½” Left, (1) 2 ½” Officer Side Bumper, (1) 2 ½” Left Rear
  • 3,500-Gallon Water Tank
  • 50-Gallon Foam Tank
  • Elkhart Foam System

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • AMDOR Roll-Up Compartment Doors
  • 60 cu. ft. Total Compartment Space
  • Body: SWT – 05B

ADDITIONAL EQUIPMENT:

  • Federal Q2B Siren, Front Bumper Mount
  • Camera System, FRC, Inview 360
  • Newton Kwik Dumps, Left/Right/Rear
  • Portable Tank Storage, Zico Elec/HYD Rack, PTS-HA
  • Whelen 60” Freedom Lightbar
  • Whelen 47” Traffic Advisor
  • Whelen L31 Beacons
  • Firetech Brow Light with Marker Lights
  • FR Spectra Scene Lights (3)
