Delivery Date:
04/14/2019
Department Name:
Madisonville IFC
Department City / State:
Madison Township, PA
Truck Type:
Sutphen Corporation – HS #6300
Dealer – Signal 1 Fire Equipment
WHEEL BASE: 254”
TRAVEL HEIGHT: 9’ – 11 ½”
TRAVEL LENGTH: 34’ – 5 ½”
CHASSIS: Freightliner 114 SD 4 Door
- Four-Door, Four-Person Cab
- Front Axle and Suspension: 20,000 lbs
- Rear Axle and Suspension: 30,000 lbs
- Engine: Cummins, L9, 450 HP
- Transmission: 3000 EVS
PUMP: Hale
- QMAX-1500, Single State Pump
- Discharge: (2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 3” Deck Gun, (1) 1 ½” Front Bumper
- Speedlays: (2) 2” with 1 ½” Swivel
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- Over 159 cu. ft. Total Compartment Space
- Ladder Chute
- Alco-Lite Ladders (PEL-24 24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)
OPTIONAL EQUIPMENT:
- 14” Extended Chrome Steel Bumper
- Whelen 62” Justice Lightbar
- Whelen M6 Warning Light
- Whelen M6 Scene Lights
- Whelen L31 Beacons
- Fire Tech Work Lights
- Zico Ladder Rack
- Light FR Spectra, LED, Tele, 15K Lumens, 12V
