Sutphen Corporation – HS #6594
Dealer – Blaze Emergency Equipment
WHEELBASE: 183”
TRAVEL HEIGHT: 10’
TRAVEL LENGTH: 33’ – 4”
CHASSIS: Kenworth T800 – 2DR
- Two-Door, Two-Person Cab
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins ISX 15, 500 HP
- Transmission: EVS 4500
PUMP: Hale
- Hale Side Kick DSD, 1250 GPM, PTO
- Discharges: (3) 2 ½” Left, (1) 4” Left Rear
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 3,500-Gallon Water Tank
BODY: Sutphen
- Amdor Roll-Up Compartment Doors
- Over 114 Cu. Ft. Compartment Space
- Body: SET-05C STS Elliptical Tanker Tandem, Integrated
ADDITIONAL EQUIPMENT:
- Federal Q2B Siren, Front Bumper Mount
- Camera System: Voyager 3
- Zico Electric/Hydraulic Rack, Portable Tank Storage
- Newton 10” Kwik Dump, STS, Left, Right and Rear
- Federal Signal 60” Navigator Lightbar
- Federal Signal LP800 Beacons
- Whelen C6 Warning Lights (6)
- Whelen 47” Traffic Advisor
