Delivery Date:
12/01/2017
Department Name:
City of Savannah Fire Department
Department City / State:
Savannah, GA

WHEEL BASE: 185″

TRAVEL HEIGHT: 9′-7 3/4″± 2″

TRAVEL LENGTH: 32′-3″

CHASSIS:              Sutphen 62” Cab with half 10” half raised roof

  • Four-Door, Eight-Person Cab
  • Front Axle and Suspension: 18,000 Lb.
  • Rear Axle and Suspension: 27,000 Lb.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-2000 GPM SINGLE STAGE
  • Discharge: 2.5″ Left, 2.5″ Left, 4” Right, 2.5″ Right, 2.5″ Left Rear, 2.5″ Right Rear, 2.5” Front Bumper, 3” Deck Gun
  • 750 Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • 9 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • Scene Lights, Whelen
  • Federal Q2B
  • Whelen 500 Series on Door Panels
  • Access Doors in side of Dunnage area
  • LED Hose bed lighting
