WHEEL BASE: 258”
TRAVEL HEIGHT: 11’-6”
TRAVEL LENGTH: 48’-6”
CHASSIS: Sutphen
- Four-Door Six-Person 62” cab with half 10” raised roof
- Front Axle and Suspension 23,000 Lbs
- Rear Axle and Suspension 44,000 Lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-1500 GPM
- Discharges- (2) 2.5“ Left, (1) 3“ Right, (1) 2.5“ Right
- 300 Gallon Tank
BODY: Sutphen
- Aluminum
- Rom Roll up Door
- Duo Safety Ladders
OPTIONAL EQUIPMENT:
- LED Hiviz Firetech Headlights
- Cab Pump Shift
- Camera, Brigade Backeye 360 Degree
- Work Lights Led, Firetech WL-2000-F-B
- Brow light, 12V Led, Firetech 72”
- Ladder Lighting system, Firetech Led
