Delivery Date:
07/30/2018
Department Name:
Ohio City Fire Department
Department City / State:
Ohio City, OH
Truck Type:
WHEEL BASE: 267″
TRAVEL HEIGHT: 10′
TRAVEL LENGTH: 35′ – 7″
CHASSIS: Commercial cab
- Two-Door, Two-Person Cab
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 52,000 lbs.
- Engine: Paccar Cummins Motor, PX-9 450HP
- Alternator: Delco 320 AMP
- Transmission: Allison 3000 EVS
PUMP: Hale
- XS QFLO-1250 GPM Single Stage
- Discharge: (2) 2.5” Left, (1) 3” Right, (1) 2.5” Right, (1) 3” Deck Gun,
- 3500 Gallon Water Tank
BODY: Sutphen
- Stainless Steel Subframe
- 3 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- 5” Storz on hard suction hose with fold in handle
- Stainless Steel Sun Visor Included with Chassis
- Pump Panel Heater
