Delivery Date:
07/30/2018
Department Name:
Ohio City Fire Department
Department City / State:
Ohio City, OH

WHEEL BASE: 267″

TRAVEL HEIGHT: 10′

TRAVEL LENGTH: 35′ – 7″

CHASSIS:             Commercial cab

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 52,000 lbs.
  • Engine: Paccar Cummins Motor, PX-9 450HP
  • Alternator: Delco 320 AMP
  • Transmission: Allison 3000 EVS

PUMP:                  Hale

  • XS QFLO-1250 GPM Single Stage
  • Discharge: (2) 2.5” Left, (1) 3” Right, (1) 2.5” Right, (1) 3” Deck Gun,
  • 3500 Gallon Water Tank

BODY:                  Sutphen

  • Stainless Steel Subframe
  • 3 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • 5” Storz on hard suction hose with fold in handle
  • Stainless Steel Sun Visor Included with Chassis
  • Pump Panel Heater
