Delivery Date:
12/01/2017
Department Name:
Bath Township Fire Department
Department City / State:
Bath, OH

WHEEL BASE: 201″

TRAVEL HEIGHT: 10′-2″ ±2″

TRAVEL LENGTH: 33′-5″

CHASSIS:              Sutphen 62” extended cab with half 10” raised roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension: 20,000 Lb.
  • Rear Axle and Suspension: 27,000 Lb.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

BODY:                   Sutphen

  • 9 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24

Pump                    Hale

  • 2000 GPM Single Stage
  • Discharge: (2) 2.5” Left, (2) 3” Right, 3” Front/Left Main Hose bed, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
  • 1000 gallon water tank

OPTIONAL EQUIPMENT:

  • Scene Lights, Whelen
  • Federal Q2B
  • Smart Power 10kw Generator
  • Glove Holders in the rear doors
